Danfoss
DT series
- 18.3 - 127.7 cu.in.
- up to 30000 lbs. in.
- up to 400 rpm
- up to 2 1/4" shaft
- up to 10000 lb.* side load capacity
- available in SAE "C" mount flanges
DR series
- 15.9 - 45.6 cu. in.
- up to 13000 lbs. in.
- up to 450 rpm
- up to 1 1/2" shaft
- up to 4400 lb.* side load capacity
- available in SAE "A" mount & wheel mount flanges
RE series
- 7.4 - 45.6 cu. in.
- up to 12000 lbs. in.
- up to 400 rpm
- up to 1 1/2" shaft
- up to 4400 lb.* side load capacity
- available in SAE "A" mount & wheel mount flanges
CE series
- 7.4 - 45.6 cu. in.
- up to 12000 lbs. in.
- up to 400 rpm
- up to 1 1/4" shaft
- up to 2100 lb.* side load capacity
- available in wheel mount flanges
HB series
- 3.2 - 24.9 cu. in.
- up to 8000 lbs. in.
- up to 800 rpm
- up to 1 1/4" shaft
- up to 1550 lb.* side load capacity
- available in SAE "A" & "B" wheel mount & 4 bolt square wheel mount flanges
RS series
- 3.2 - 24.9 cu. in.
- up to 6500 lbs. in.
- up to 550 rpm
- up to 1" shaft
- up to 530 lb.** side load capacity
- available in SAE "A" & "B" wheel mount & 4 bolt wheel mount flanges
Motor / Brake
- 3.2 - 127.7 cu. in.
- up to 14000 lbs. in. holding torque
- 200 - 400 psi release pressure
Flow Dividers
- 2-40 gpm
- up to 4000 psi peak
- quiet operation
BK Brake
- up to 14000 lbs. in. holding torque
- 400 psi release pressure
- 3500 psi max. release pressure
Speed Sensor
- digital sensor
- available in 30, 50, 60, 100, and 120 pulses
